| Categories | 12V Battery |
|---|---|
| Brand | Matrix Lead acid battery |
| Model | NP150-12 |
| Battery brand | Matrix |
| Cover | ABS |
| Safety valve | Rubber |
| FOB port | shenzhen |
| Terms of Payment | L/C,D/A,D_P,Western Union,MoneyGram,T/T |
Specification :
|
Battery Model |
NP 150-12 12V150AH |
|||
|
Designer Floating Life |
Up to 5 Years |
|||
|
Capacity (25℃) |
20HR(7.50A,10.8V) |
10HR(15.0A,10.8V) |
5HR(25.5A,10.8V) |
1HR(83.5A,10.5V) |
|
|
150.0AH |
150.0AH |
127.5AH |
83.5AH |
|
Dimensions |
Length |
Width |
Height |
Total Height |
|
|
486mm (19.13inch) |
171mm (6.73inch) |
233mm (9.17inch) |
243mm (9.57inch) |
|
Approx. Weight |
42.30Kg (93.27 lbs) |
|||
|
Internal Resistance |
Full charged at 25℃:≤6.3mΩ |
|||
|
Self Discharge |
2% of capacity declined per month at (25℃) |
|||
|
Capacity Affected by Temp.(20HR) |
40℃ |
25℃ |
0℃ |
-15℃ |
|
|
102% |
100% |
85% |
65% |
|
Charge Voltage(25oC) |
Cycle use |
Float use |
||
|
|
14.4-14.6V(-30mV/℃), max. Current: 37.5A |
13.6-13.8V (-20mV/℃) |
||
VRLA Battery
Application:
Construction:
