| Categories | UPS battery |
|---|---|
| Brand | Matrix Lead acid battery |
| Model | NP7 -12 |
| color | black |
| Business Type | Factory |
| Certificate | CE,ISO9001,IEC,MSDS |
| Production Capacity | 300,000pcs/months |
| Name | 12v 7ah battery |
| case | ABS |
| More | |
| FOB port | Shenzhen or Guangzhou |
| Terms of Payment | L/C,Western Union,T/T |
| Download DOC | NP7 -12.xlsx |
| Update Time | 12-18-2015 |
Rechargeable sealed lead acid battery 12v 7ah CE ISO9001
specifications:
|
Nominal Voltage |
12V |
|||
|
Rated capacity(20 hour rate) |
7AH |
|||
|
Dimensions |
Length |
151±1mm(9.02inches) |
||
|
Width |
65±1mm(5.43inches) |
|||
|
Height |
94±1mm(8.19inches) |
|||
|
Total Height |
100±1mm(8.30inches) |
|||
|
Weight Approx |
|
2.05Kg(4.52bs) |
||
Application
UPS(uninterruptible power supply)
Emergency Power Supply
Safety and Security system
Solar Power system
Lighting products
Portable Power Supply
Parking Lock
Electronic Scale
Traffic Sign Light
Features
1.Low self discharge: lower than 3% of rated capacity per month under normal
operating temperature.
2.ABS case (can be made with flame retardant V0)
3.No memory effect after repetitious usage or discharges
4.Maintenance-free operation
5.Sealed construction and leak proof
6.Safety valve regulated system
7.Operating in any position
8.Deep discharge recovery
9.Wide operating temperature range
| MODEL | VOLTAGE | CAPACITY | DIMENSIONS | TERMINAL | ||||||||
| LENGTH | WIDTH | HEIGHT | TOTAL HEIGHT | TYPE | PLACE | |||||||
| (V) | (Ah) | mm | inch | mm | inch | mm | inch | mm | inch | |||
| NP0.8-12 | 12 | 0.8 | 96 | 3.78 | 25 | 0.98 | 62 | 2.44 | 62 | 2.44 | PLUG | O |
| NP1.2-12 | 12 | 1.2 | 97 | 3.82 | 43 | 1.69 | 51 | 2.05 | 57 | 2.28 | T1 | E |
| NP2.0-12 | 12 | 2.0 | 151 | 5.94 | 20 | 0.79 | 89 | 3.50 | 89 | 3.5 | T1 | C |
| NP2.2-12 | 12 | 2.2 | 178 | 7.01 | 35 | 1.38 | 61 | 2.40 | 67 | 2.64 | T1 | C |
| NP2.6-12 | 12 | 2.6 | 70 | 2.76 | 48 | 1.89 | 98 | 3.86 | 104 | 4.09 | T1 | C |
| NP3.2-12 | 12 | 3.2 | 134 | 5.28 | 67 | 2.64 | 61 | 2.40 | 67 | 2.64 | T1 | E |
| NP3.4-12 | 12 | 3.4 | 134 | 5.28 | 67 | 2.64 | 61 | 2.40 | 67 | 2.64 | T1 | E |
| NP4-12 | 12 | 4 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 107 | 4.21 | T1 | C |
| NP4.5-12 | 12 | 4.5 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 107 | 4.21 | T1 | C |
| NP5-12 | 12 | 5 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 107 | 4.21 | T1 | C |
| NP7-12 | 12 | 7 | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.94 | T1/T2 | F |
| NP7.2-12 | 12 | 7.2 | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.94 | T1/T2 | F |
| NP7.5-12 | 12 | 7.5 | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.94 | T1/T2 | F |
| NP8.5-12 | 12 | 8.5 | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.94 | T1/T2 | F |
| NP9-12 | 12 | 9 | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.94 | T1/T2 | F |
| NP10-12A | 12 | 10 | 151 | 5.94 | 65 | 2.56 | 111 | 4.37 | 117 | 4.61 | T1/T2 | F |
| NP12-12 | 12 | 12 | 151 | 5.94 | 98 | 3.86 | 96 | 3.74 | 101 | 3.98 | T2 | F |
| NP14-12 | 12 | 14 | 151 | 5.94 | 98 | 3.86 | 96 | 3.74 | 101 | 3.98 | T2 | F |
| NP17-12 | 12 | 17 | 181 | 7.13 | 76 | 3.03 | 167 | 6.57 | 167 | 6.57 | T3/T8 | D |
| NP18-12 | 12 | 18 | 181 | 7.13 | 76 | 3.03 | 167 | 6.57 | 167 | 6.57 | T3/T8 | D |
| NP20-12 | 12 | 20 | 181 | 7.13 | 76 | 3.03 | 167 | 6.57 | 167 | 6.57 | T3/T8 | D |
| NP24-12 | 12 | 24 | 166 | 6.54 | 175 | 6.89 | 125 | 4.92 | 125 | 4.92 | T3/T8 | D |
| NP24-12A | 12 | 24 | 165 | 6.50 | 125 | 4.92 | 175 | 6.89 | 175 | 6.89 | T6/T8 | D |
| NP26-12 | 12 | 26 | 166 | 6.54 | 175 | 6.89 | 127 | 5.00 | 127 | 5.00 | T3 | D |
| NP28-12 | 12 | 28 | 166 | 6.54 | 175 | 6.89 | 125 | 4.92 | 125 | 4.92 | T3/T8 | D |
| NP28-12A | 12 | 28 | 165 | 6.50 | 125 | 4.92 | 175 | 6.89 | 182/175 | 7.17/6.89 | T6/T8 | D |
| NP33-12 | 12 | 33 | 195 | 7.68 | 130 | 5.12 | 155 | 6.10 | 180/166 | 7.1/6.7 | T7/T9 | C |
| NP35-12 | 12 | 35 | 195 | 7.68 | 130 | 5.12 | 155 | 6.10 | 180/166 | 7.1/6.7 | T7/T9 | C |
| NP38-12 | 12 | 38 | 198 | 7.76 | 166 | 6.50 | 170 | 6.69 | 170 | 6.69 | T4/T9 | D |
| NP40-12 | 12 | 40 | 198 | 7.76 | 166 | 6.50 | 170 | 6.69 | 170 | 6.69 | T4/T9 | D |
| NP45-12 | 12 | 45 | 198 | 7.76 | 166 | 6.50 | 170 | 6.69 | 170 | 6.69 | T4/T9 | D |
| NP50-12 | 12 | 50 | 229 | 9.02 | 138 | 5.43 | 208 | 8.19 | 230/211 | 9.1/8.3 | T5/T9 | C |
| NP55-12 | 12 | 55 | 229 | 9.02 | 138 | 5.43 | 208 | 8.19 | 230/211 | 9.1/8.3 | T5/T9 | C |
| NP65-12 | 12 | 65 | 350 | 13.78 | 167 | 6.57 | 178 | 7.05 | 185/178 | 7.3/7.1 | T5/T9 | C |
| NP75-12 | 12 | 75 | 262 | 10.31 | 170 | 6.69 | 210 | 8.27 | 230 | 9.06 | T6/T9 | C |
| NP80-12 | 12 | 80 | 262 | 10.31 | 170 | 6.69 | 210 | 8.27 | 230 | 9.06 | T6/T9 | C |
| NP90-12 | 12 | 90 | 331 | 12.99 | 175 | 6.73 | 216 | 8.43 | 224/220 | 8.8/8.7 | T5/T9 | C |
| NP100-12 | 12 | 100 | 331 | 12.99 | 175 | 6.73 | 216 | 8.43 | 224/220 | 8.8/8.7 | T5/T9 | C |
| NP100-12A | 12 | 100 | 409 | 16.10 | 175 | 6.73 | 225 | 8.86 | 225 | 8.86 | T5/T11 | C |
| NP120-12 | 12 | 120 | 409 | 16.10 | 175 | 6.73 | 225 | 8.86 | 225 | 8.86 | T5/T11 | C |
| NP150-12 | 12 | 150 | 485 | 19.09 | 170 | 6.69 | 240 | 9.45 | 240 | 9.45 | T5/T11 | C |
| NP180-12 | 12 | 180 | 522 | 20.60 | 235 | 9.30 | 218 | 8.60 | 225 | 8.9 | T5/T11 | E |
| NP200-12 | 12 | 200 | 522 | 20.60 | 235 | 9.30 | 218 | 8.60 | 225 | 8.9 | T5/T11 |
E |
